TBarCode/SAPwin:適用于SAP®的條碼DLL
TEC-IT 出品的 SAP 條碼 DLL 是一款適用于 SAPSprint, SAPlpd 和 SAPGUI (SAPWIN DLL) 的擴展軟件。通過使用此條碼 DLL 您可以在所有打印機上打印條碼無需額外硬件設備。


您想使用 SAP® ERP, SAP R/3® 或 mySAP® ERP 打印條碼嗎?
· 您希望幾乎在您公司的每一臺打印機都能打印條碼嗎?當然,也都支持所有無特殊條碼功能的打印機嗎?
幾乎每一個打印機在你的公司應該成為條形碼啟用?在邏輯上也沒有特殊的打印機條形碼支持?
· 您已經擁有了一個 Windows 打印服務器用于運行 (SAPsprint 或 SAPlpd) 或者您希望直接在客戶端 (SAPGUI) 打印條碼文件呢?
· 您需要的不僅僅是普遍的線性條碼 (如:Code-39, Code-128, EAN-Codes...),而且您還需要二維條碼符號,如: PDF417, Data Matrix 或 QR-Code 嗎?
· 需要獨立于硬件的解決方案,可在幾乎每個打印機并且無需打印機擴展 下工作 (如:條碼 DIMM/SIMM 模型)嗎?
· 并且您希望有熟練的技術支持嗎?
1. 下載TBarCode/SAPwin - 適用于 SAP 的條碼 DLL。
2. 在 Windows SAP 客戶端或打印服務器上安裝此 SAP 條碼 DLL (作為擴展線軸傳遞程序 SAPSprint 或 SAPlpd)。
3. 添加一個打印機設備類型 SWIN (in transaction SPAD) 并通過您所安裝的 TBarCode/SAPwin 服務器 (或客戶端) 進行打印。
4. 至此 - 您已經打印完條碼了。

TBarCode/SAPwin 作為條碼DLL 擴展 SAP 線軸傳輸程序 SAPsprint 和 SAPlpd 使用條碼打印。另外,TBarCode/SAPwin 可用于 Windows 的 SAPGUI 客戶端操作。
主要優點是....
· 所有普遍的線性和二維條碼是對于工業和貿易提供的一種產品。
· 條碼打印只需獨立打印機且無需硬件擴展。在任何時候都可以更換打印機。被支持的打印機型號范圍很廣 (通過 SAP 線軸傳輸程序與 Windows 打印機驅動激活)。
· 在打印服務器和Windows客戶端的操作都可行。
· 簡單易用的免費安裝。
· 所有文檔中的簡單使用 (SAPscript, SmartForms, ABAP) 與系統條碼和打印控件。
· 盡可能高品質的輸出生成條碼。支持適應碳粉或墨水飽和的延伸。
· 對于二維條碼沒有數據限制:您可以在每個符號打印幾千個Bytes。
· 非常符合成本效益…
每個打印機的成本:無。更換打印機成本:無。硬件升級成本:無。打印機字體下載:無。SAP 形式修改:無。安裝需求(系統級) :幾乎為零。產品技術支持:免費!
在打印工作進程時,TBarCode/SAPsprint 在 SAPWIN 數據流中轉化打印控件至相應的條碼中并對于打印機設備生成恰當?shù)?GDI 圖形指令。
所有被支持的條碼格式可通過一個簡單的界面進行配置。所有的打印機可以通過被執行的 Windows 打印機驅動程序被使用。
條碼專門由我們的軟件生成,也就是說,在盡可能高的分辨率和輸出品質下生成條碼。這樣您便可以獨立配備您的所有打印機硬件并且在企業范圍擴大條碼能力。
TEC-IT 的條碼 DLL 是一款適用于 SAPsprint,SAPlpd 和 SAPGUI 條碼打印的擴展軟件。無需購買特別硬件或特定打印機。
· SAPsprint, SAPlpd 和SAPGUI (SAPWIN.dll)的條形碼擴展
· 為 SAPlpd 版本3或更高
· 為SAPSprint V1.0.0.1 或更高(32 Bit and 64 Bit Version)
· 為SAPGUI 和 SAPwin.dll V1.0.0.6 或更高(32 Bit 和64 Bit Version)
· 為EH&S WWI SP31
· 為Microsoft® Microsoft Windows XP SP3, 2003, Vista, 7, Server 2008 (32 + 64 Bit), 2008R2, 8, 2012R2, 10
· 為SAP R/3 Release 2.2 和所有新的SAP ERP 系統
· 用SPAD Host Spool Access F, S, U 或G與所有SAPWIN/ SWIN根據設備類型組合
· 通過系統條碼,條碼打印機和Printcontrols條碼管理.
· 適合SAPscript, SmartForms 和ABAP
· Barcode Symbologies
所支持的Bar Codes
|
CodaBar 2 Widths |
CodaBar (2 Width), CodaBar2 |
|
Code 2OF5 IATA |
Code 2 of 5 IATA Version (International Air Transport Association) |
|
Code 2OF5 Industry |
Code 2 of 5 Industry Version |
|
Code 2OF5 Interleaved |
Code 2 of 5 Interleaved (alias ITF or Code 2/5 IL), |
|
Code 2OF5 Matrix |
Code 2 of 5 Matrix (alias 2of5 Standard) |
|
Code 2OF5 Standard |
Code 2 of 5 (identical with Code 2 of 5 Matrix) |
|
Code 32 |
Code 32 (Italian Pharmacode) |
|
Code 39 |
Code 3 of 9 alias Code-39 |
|
Code 39 Full ASCII |
Code 3 of 9 Extended Version (ASCII) |
|
Code 93 |
Code 93 |
|
Code 93 Full ASCII |
Code 93 Extended Version (ASCII) |
|
Code128 |
Code-128 all sub sets and Compressed Mode |
|
Code128A |
Code 128 Subset A |
|
Code128B |
Code 128 Subset B |
|
Code128C |
Code 128 Subset C |
|
EAN8 |
EAN-8 (also JAN or IAN) |
|
EAN8P2 |
EAN-8 (also JAN or IAN) with 2 digit add-on |
|
EAN8P5 |
EAN-8 (also JAN or IAN) with 5 digit add-on |
|
EAN13 |
EAN-13 (also JAN or IAN), |
|
EAN13 P2 |
EAN-13 (also JAN or IAN) with 2 digit add-on |
|
EAN13 P5 |
EAN-13 (also JAN or IAN) with 5 digit add-on |
|
EAN14 |
EAN-14 (GTIN coded with GS1/EAN-128 symbology) |
|
EAN128 |
EAN-128 alias UCC-128 alias GS1-128 |
|
Flattermarken |
Flattermarken |
|
GS1-128 |
GS1-128, identical to EAN-128 / UCC-128 |
|
GS1-DataBar |
GS1-DataBar Symbologies (all based upon RSS Codes) |
|
ISBN-13 |
ISBN-13 (International Standard Book Number, 13 digits) |
|
ISBN13-P5 |
ISBN13 with 5 digit supplement |
|
ISMN |
ISMN (International Standard Music Number) |
|
ISSN |
ISSN (International Standard Serial Number) |
|
ISSN P2 |
ISSN with 2 digit supplement |
|
ITF-14 |
ITF14, Code 2of 5 Interleaved (14 digits) |
|
LOGMARS |
DOD Logmars, Department of Defense Logmars |
|
MSI |
MSI Barcode variants with different check digits |
|
Pharmacode One-Track |
Pharmacode One Track (1 Track) |
|
Pharmacode Two-Track |
Pharmacode Two Track (2 Track) |
|
PLANET 12 Digit |
Planet Code 12 digits (Postal Alpha Numeric Encoding Technique) |
|
PLANET 14 Digit |
Planet Code 14 digits |
|
Plessey |
Plessey Unidirectional |
|
Plessey Bidirectional |
Plessey Bidirectional |
|
PZN7 |
Pharmazentralnummer Germany (PZN/PZN7) |
|
PZN8 |
Pharmazentralnummer Germany (PZN8) |
|
RSS Expanded |
EAN/UCC RSS Expanded (Reduced Space Symbology) |
|
RSS Limited |
EAN/UCC RSS Limited (Reduced Space Symbology) |
|
RSS-14 |
EAN/UCC RSS14 (Reduced Space Symbology) |
|
RSS-14 Truncated |
EAN/UCC RSS14 Truncated (Reduced Space Symbology) |
|
RSS-14 Limited |
EAN UCC RSS14 Limited (Reduced Space Symbology) |
|
SSCC-18 |
SSCC 18 Shipping Container Code |
|
Telepen |
Telepen |
|
Telepen Alpha |
Telepen Alphanumeric |
|
UCC/EAN-128 |
UCC/EAN 128 |
|
UCC-128 |
UCC 128 |
|
UPC12 / UPCA |
UPC 12 (alias UPC-A), |
|
UPC-A |
UPC A (alias UPC-12), |
|
UPC-A P2 |
UPC Version A + 2 digit supplement |
|
UPC-A P5 |
UPC Version A + 5 digit supplement |
|
UPC-E |
UPC Version E |
|
UPC-E P2 |
UPC Version E + 2 digit supplement |
|
UPC-E P5 |
UPC Version E + 5 digit supplement |
|
UPCSCC |
UPC Shipping Container Code (refer to ITF14, SCC-14) |
|
VIN / FIN |
Vehicle Identification Number, Fahrzeug-Identifizierungsnummer |
Postal Codes (1D Postal Barcodes)
|
Australian Post Custom |
Australian Post Standard Customer, Customer2, Customer 3 |
|
Australian Post Redirect |
Australian Post Redirection |
|
Australian Post Reply Paid |
Australian Post Reply Paid |
|
Australian Post Routing |
Australian Post Reply Routing |
|
Brazilian CEPNet |
Brasilianischer Post-Barcode |
|
DAFT Code |
DAFT is an artificial generic code |
|
DPD Code |
German Parcel Service Label Code |
|
DP Identcode |
Deutsche Post Identcode |
|
DP Leitcode |
Deutsche Post Leitcode |
|
Italian Postal 2of5 |
Italian Postal Code (based on 2of5 IL) |
|
Italian Postal 3of9 |
Italian Postal Code (based on Code 39) |
|
Japan Postal |
Japan Postal 4-State Bar Code |
|
KIX |
Dutch Postal Barcode |
|
Korean Postal Authority |
Korean Postal Barcode |
|
RoyalMail 4State (RM4SCC) |
Royal Mail 4 State Barcode (RM4SCC) |
|
USPS OneCode (4-CB) |
see USPS Intelligent Mail® Barcode |
|
USPS Intelligent Mail® Barcode |
USPS Intelligent Mail® Barcode, alias USPS OneCode alias USPS 4-State Customer Barcode |
|
USPS PostNet5 |
USPS PostNet ZIP (5 digits) with check digit computation |
|
USPS PostNet9 |
USPS PostNet ZIP+4 (9 digits) with check digit computation |
|
USPS PostNet11 |
USPS PostNet ZIP+4+2 (11 digits) with check digit computation |
Two Dimensional Barcodes (2D Barcodes)
|
Aztec Code |
Aztec Code (available in TBarCode/SAPwin Version 8+) |
|
Codablock-F |
CodablockF (Stacked Code128), used by HIBC |
|
Data Matrix (ECC200 standard with error correction) |
|
|
DP Postmatrix |
Deutsche Post Werbeantwort Postmatrix |
|
Data Matrix with GS1 format (ECC200, FNC1), Auto Compaction |
|
|
MaxiCode™ |
Maxi Code™ (used by UPS®) |
|
Micro QR-Code |
Micro QRCode (Micro Quick Response Code, available in TBarCode V9 & Barcode Studio V9) |
|
MicroPDF417 |
Micro PDF-417, MicroPDF |
|
PDF-417 (used by VDA, GTL, ODETTE, VDA Belom...), |
|
|
PDF417 Truncated |
PDF-417 Truncated Version |
|
Quick Response Code (ISO/IEC 18004:2000); uses 932/Shift-JIS standard character set |
|
|
QR-Code 2005 |
QRCode 2005 (ISO/IEC 18004:2006); uses Latin-1 (ISO-5589-1) as standard character set |
|
RSS-14 Stacked |
EAN/UCC RSS14 Stacked |
|
RSS-14 Stacked Omnidir |
EAN/UCC RSS14 Stacked Omnidirectional |
|
RSS Expanded Stacked |
EAN/UCC RSS Expanded Stacked |
HIBC Barcodes (available in TBarCode/SAPwin Version 9+)
|
HIBC LIC 128 |
HIBC LIC variant of Code 128 |
|
HIBC LIC 39 |
HIBC LIC variant of Code 39 |
|
HIBC LIC Codablock-F |
HIBC LIC variant of Codablock-F |
|
HIBC LIC Data Matrix |
HIBC LIC variant of Data Matrix |
|
HIBC LIC MicroPDF417 |
HIBC LIC variant of MicroPDF417 |
|
HIBC LIC PDF417 |
HIBC LIC variant of PDF417 |
|
HIBC LIC QR-Code |
HIBC LIC variant of QR-Code |
|
HIBC PAS 128 |
HIBC PAS variant of Code 128 |
|
HIBC PAS 39 |
HIBC PAS variant of Code 39 |
|
HIBC PAS Codablock-F |
HIBC PAS variant of Codablock-F |
|
HIBC PAS Data Matrix |
HIBC PAS variant of Data Matrix |
|
HIBC PAS MicroPDF417 |
HIBC PAS variant of MicroPDF417 |
|
HIBC PAS PDF417 |
HIBC PAS variant of PDF417 |
|
HIBC PAS QR-Code |
HIBC PAS variant of QR-Code |
EAN-UCC Composite Variants
|
RSS-14 |
Composite Component CC-A / CC-B |
|
RSS-14 Stacked |
Composite Component CC-A / CC-B |
|
RSS-14 Stacked Omnidirectional |
Composite Component CC-A / CC-B |
|
RSS Limited |
Composite Component CC-A / CC-B |
|
RSS Expanded |
Composite Component CC-A / CC-B |
|
RSS Expanded Stacked |
Composite Component CC-A / CC-B |
|
EAN 13 |
Composite Component CC-A / CC-B |
|
EAN 8 |
Composite Component CC-A / CC-B |
|
UPC A |
Composite Component CC-A / CC-B |
|
UPC E |
Composite Component CC-A / CC-B |
|
UCC/EAN128 |
Composite Component CC-A / CC-B / CC-C |
GS1 DataBar Composite Variants (2D Barcodes)
|
Composite Component CC-A / CC-B |
|
|
GS1 DataBar Stacked |
Composite Component CC-A / CC-B |
|
GS1 DataBar Stacked Omni |
Composite Component CC-A / CC-B |
|
GS1 DataBar Limited |
Composite Component CC-A / CC-B |
|
GS1 DataBar Expanded |
Composite Component CC-A / CC-B |
|
GS1 DataBar Expanded Stacked |
Composite Component CC-A / CC-B |
|
Barcode types |
Print Control parameter "C" specifies the bar code type. |
|
Width |
Specification in mm / Print Control parameter "B" |
|
Height |
Specification in mm / Print Control parameter "H" |
|
Check-Digit |
yes/no - depending on bar code / Print Control parameter "P" |
|
Human readable text |
yes/no / Print Control parameter "A" |
|
Position x, y |
Specification in mm or actual cursor position / Print Control parameters "X" and "Y" |
|
Bar Width Ratio |
User specified ratio or standard ratio (depending on bar code type) / Print Control parameters "S1".."S4" |
|
Space Width Ratio |
User specified ratio or standard ratio (depending on bar code type) / Print Control parameters "L1".."L4" |
高級條碼設置
· 像素修剃用以盡量減少在普通打印方法上的印刷公差。
· 對于條碼位置垂直調整的全局移動參數 (避免格式中的更改,補償打印設備中的差異)。
· 激活普遍工業默認值 (兼容條碼 DIMM/SIMM 模塊)。
· 在 EAN/UPS 代碼中對于人類可閱讀文本的全局字體風格設置 (在設備類型中更改或者格式是非必要的)。
· 方向(0°, 90°, 180°, 270°)
· 校驗碼計算方法
· 模寬,條碼寬度比
· 適用于條碼變量的代碼子集
· 二進制編碼和非打印字符的編碼
· 轉義序列 ("測試\13" == "測試" + 回車)
· 2D 條碼符號的擴展參數 (線高,錯誤修正級別,列,,...)
· 對于排除故障的廣泛數據記錄能力。
